FS-A71
|
|
PICMG
1.3 CPU Card support Intel® Core 2 Duo mobile CPU
|
|
|
|
Intel® CoreTM 2 Duo
( Merom )processor @ 800 MHz FSB
Intel® GME965
& ICH8M , DDRII 533 / 677
MHz up to 3.0 GB , Onboard VGA
24-bit Dual
Channel LVDS , 2 x Mini-PCI sockets
Onboard 2 x Intel® Gigabit LAN ,
HD Audio , CF socket
RS232/422/485 , 6 x USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA ,
|
|
|
|
|
|
FS-A70
|
|
PICMG
1.3 CPU Card support Intel® Core 2 Quad CPU
|
|
|
|
Intel® CoreTM
2 Duo / CoreTM 2
Quad processor , 533 / 800 / 1066 MHz FSB
Intel®
Q965 & ICH8DO chipset
DDRII 533 / 677/
800
MHz up to 3.0 GB , Onboard VGA
Onboard 2 x Intel Gigabit LAN ,
6 x SATA with RAID 0/1/5/10
RS232/422/485 , USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
, Mini-PCI
|
|
|
|
|
|
FS-97D
|
|
PICMG
1.0 support Intel® Core 2 Quad CPU
@ 1333 MHz FSB
|
|
|
|
Intel® CoreTM
2 Duo / CoreTM 2
Quad, 800 / 1066 / 1333 MHz FSB
Intel®
Q35 & ICH9DO chipset
DDRII 677/
800
MHz up to 4.0 GB , Onboard VGA , Optional DVI or LVDS
2 x Intel Gigabit LAN ,
6 x SATA with RAID 0/1/5/10
RS232/422/485 , USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
, Mini-PCI
|
|
|
|
|
|
FS-97C
|
|
PICMG
1.0 CPU Card support Intel® Core 2 Duo Mobile CPU
|
|
|
|
Intel® CoreTM 2 Duo / CoreTM Duo processor , 533 / 667 MHz FSB
Intel® 945GME and
ICH7M chipset
DDRII 533 / 677
MHz up to 3.0 GB , Onboard VGA
18-bit Dual
Channel LVDS & DVI interface
Onboard 2 x Intel Gigabit LAN ,
5.1 channel Audio
RS232/422/485 , USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
2 x Mini-PCI &
CompactFlash socket
|
|
|
|
|
|
|
|
PICMG 1.0 CPU Card support Intel® Core 2 Duo
CPU
|
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo processor , 533 / 800 / 1066 MHz FSB
Intel®
Q965 & ICH8DO chipset
DDRII 533 / 677/
800
MHz up to 3.0 GB , Onboard VGA
Optional 24-bit Dual
Channel LVDS or DVI interface
Onboard 2 x Intel Gigabit LAN ,
6 x SATA with RAID 0/1/5/10
RS232/422/485 , USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
, Mini-PCI
|
|
|
|
|
|
FS-97A
|
|
Intel® Pentium M Full-size PICMG CPU Card
|
|
|
|
Intel® Pentium M & Celeron M processor-based running
up to 2 GHz with Intel® 855GME & ICH4, 2 GB DDR SDRAM,
100 Mbps & Gigabit Ethernet port , 4 x USB 2.0, 2 x COM
1 x Printer Port, AC97 3D Audio, CompactFlash Interface,
8-bit Digital I/O, Mini-AGP socket, 24-bit LVDS
|
|
|
|
|
|
|
FS-979
|
|
LGA
775 Pentium 4 Full-size
PICMG CPU Card
|
|
|
|
Intel® LGA775 Pentium 4 Prescott processor-based running
up to 3.6+ GHz with Intel® 915GV & ICH6R , 4GB DDR2, 3x
Gigabit Ethernet port , 4 x USB 2.0 , 2 x COM , 1 x SIR ,
AC97 3D Audio, 1 x Compact Flash Socket, 8-bit digital I/O,
1 x Parallel Port,4 x SATA, DVI Interface.
|
|
|
|
|
|
|
|
Value Intel® Pentium 4 DDR Platform
|
|
|
|
Full-size PICMG Socket 478 Pentium 4 DDR CPU Card
Intel® 845G Series Chipset with ICH4
Intel® Pentium 4 / Celeron CPU @ 533/400 MHz FSB
2 GB DDR200/266 SDRAM
Intel® Extreme Graphics with 266 MHz VGA Core and 256-bit 3D Engine
Onboard Optional Dual Intel®PRO/100+ LAN
Hi-Speed USB 2.0 Interface with up to 480 Mbps Data Transfer Bandwidth
AC97 3D Audio, DiskOnChip and ISA 64mA High Drive Capacity
|
|
|
|
|
|
Socket 370 Platform with Onboard LVDS
|
|
|
|
Intel® Tualatin Pentium-III / Celeron, VIA C3 CPU @ 100/133 MHz FSB
1 GB SDRAM / ECC
Onboard 128-bit 3D Graphic Engine Chipset
with 36-bit LVDS/TTL Flat Panel / CRT SVGA with 8/16/32 MB VRAM
10/100Mbps LAN, AC97 3D Audio
CompactFlash Interfaces
Onboard Optional AV/S-Video TV-out Interface
|
|
|
|
|
|
Full-size PICMG 1.0 SBC support Intel Pentium 4 / Celeron
|
|
|
|
Intel® Tualatin Pentium-III / Celeron, VIA C3 CPU @ 100/133 MHz FSB
1 GB SDRAM / ECC
Onboard 128-bit 3D Graphic Engine Chipset
with 36-bit LVDS/TTL Flat Panel / CRT SVGA with 8/16/32 MB VRAM
10/100Mbps LAN, AC97 3D Audio
CompactFlash Interfaces
Onboard Optional AV/S-Video TV-out Interface
|
|
BackToTop
|
|
|
Half-size ISA/PCI/PISA CPU Card / Slot PC
|
|
|
|
HS-770
|
Intel® Pentium M / Celeron M
PCI CPU Card
|
|
|
Half-size
PCI-bus
Intel®
Pentium M / Celeron M with 400/533 MHz FSB.
Intel®
915GME & ICH6M chipset , 2 x DDRII DIMMS
Support
24-bit LVDS , Onboard Dual Gigabit LAN and SATA
AC97 3D
Audio , support CompactFlash type-II
3 x RS232
& 1 x RS232/422/485 ports , 4 x USB 2.0 ports
|
|
|
|
|
HS-874P
|
Intel®
Core 2 Quad / Core 2 Duo PISA CPU Card
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop , 800/1066/1333 MHz FSB Intel®
Q35 & ICH9DO , DDRII 667/800 MHz up to 2.0 GB
Onboard VGA ,
Optional DVI or 24-bit LVDS interface
Onboard 1 x Intel® Gigabit LAN ,
HD Audio , 4 x SATA with RAID
1 x RS-232/422/485 & 1 x
RS232 , 4 x USB 2.0 , IrDA , GPIO
|
|
|
|
|
HS-872P
|
Intel®
Core 2 Duo / Core Duo PISA CPU Card
|
|
|
Intel® CoreTM
2 Duo / CoreTM Duo processor , 533 / 667 MHz FSB
Intel® 945GME
& ICH7M
DDRII 533 / 677
MHz up to 2.0 GB , Onboard VGA
18-bit Dual
Channel LVDS & DVI interface
Onboard 2 x Intel® Gigabit LAN ,
5.1 channel Audio
RS232/422/485 , USB 2.0 , 8-bit GPIO , LPT , FDD , IrDA
1 x Mini-PCI &
CompactFlash socket
|
|
|
|
|
|
|
|
|
Half-size PISA-bus
Onboard Intel® Mobile Celeron 1.2GHz 256KB cache @400MHz FSB
uFCPGA CPU with Intel 82852GM & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port , 2 x USB 2.0 , 2 x COM , 1 x Printer Port
AC97 3D Audio , CompactFlash Interface , 8-bit Digital I/O,
24-bit Dual LVDS
|
|
|
|
|
|
|
|
|
Half-size PISA-bus
Onboard Intel® ULV Celeron M 600MHz, @400MHzFSB
uFCBGA CPU with Intel® 852GM & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port , 2 x USB 2.0 , 2 x COM , 1 x Printer Port
AC97 3D Audio , CompactFlash Interface , 8-bit Digital I/O,
24-bit Dual LVDS
|
|
|
|
|
|
|
|
|
Half-size PISA-bus
Intel® Pentium M & Celeron M, processor-based running
up to 2 GHz with Intel® 855GME & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port , 2 x USB 2.0 , 2 x COM , 1 x Printer Port
AC97 3D Audio , CompactFlash Interface , 8-bit Digital I/O,
24-bit Dual LVDS
|
|
|
|
|
HS-870SCM6
|
Intel®
ULV Celeron M 600 MHz ISA CPU Card
|
|
|
Half-size ISA-bus
Onboard Intel® ULV Celeron M 600MHz, @400MHzFSB
uFCBGA CPU with Intel® 852GM & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port , 2 x USB 2.0 , 2 x COM , 1 x Printer Port
AC97 3D Audio , CompactFlash Interface , 8-bit Digital I/O,
24-bit Dual LVDS
|
|
|
|
|
HS-870S
|
Intel®
Pentium M ISA CPU Card
|
|
|
Half-size ISA-bus
Intel® Pentium M & Celeron M, processor-based running
up to 2 GHz with Intel® 855GME & ICH4, 1GB DDR SDRAM ,
Gigabit Ethernet port , 2 x USB 2.0 , 2 x COM , 1 x Printer Port
AC97 3D Audio , CompactFlash Interface , 8-bit Digital I/O,
24-bit Dual LVDS
|
|
|
|
|
|
|
|
|
Half-size PISA-bus
Intel® Tualatin Pentium-III / Celeron, VIA C3 CPU @ 100/133 MHz FSB
Onboard 128-bit 3D Graphic Engine Chipset
with 18-bit LVDS/TTL Flat Panel / CRT SVGA with 8/16/32 MB VRAM
10/100Mbps LAN, AC97 3D Audio
CompactFlash, PC104 Interfaces
|
|
|
|
|
|
|
|
Half-size ISA-bus
Intel® Tualatin Pentium-III / Celeron, VIA C3 CPU @ 100/133 MHz FSB
Onboard 128-bit 3D Graphic Engine Chipset
with 18-bit LVDS/TTL Flat Panel / CRT SVGA with 8/16/32 MB VRAM
10/100Mbps LAN, AC97 3D Audio
CompactFlash, PC104 Interfaces
|
|
|
|
|
|
|
|
Half-size PISA-bus Embedded VIA Eden / C3 CPU Card
Onboard VIA Eden 533 or C3 800 MHz CPU @ 133 MHz FSB
Onboard 3D SVGA with Optional TMDS Panel Link Interface
Onboard 10/100 Mbps LAN, AC97 3D Audio, DiskOnChip Interfaces
ISA 64mA High Drive Capacity
|
|
|
|
|
|
|
|
Half-size ISA-bus Embedded VIA Eden / C3 CPU Card
Onboard VIA Eden 533 or C3 800 MHz CPU @ 133 MHz FSB
Onboard 3D SVGA with Optional TMDS Panel Link Interface
Onboard 10/100 Mbps LAN, AC97 3D Audio, DiskOnChip Interfaces
ISA 64mA High Drive Capacity
|
|
|
|
|
Half-size
ISA-bus SBC with Onboard STPC up to 133 MHz
|
|
|
Half-size ISA-bus with low power SOC CPU
STPC Consumer-II Powerful X86 Core processor up to 133 MHz.
Onboard 32 MB SDRAM ( Max 256 MB), Winbond W83977G-A Super IO
Integrated 135 MHz triple RAMDAC support resolution up to 1280 x 1024 at 75 Hz
Realtek RTL8100B 10/100 bit/s Ethernet , 1 x Compactflash socket
1 x 16-bit PC/104 connector,1 x FDD , 1 x LPT , 1 x IrDA , 1 x DOC socket
1 x DB15 VGA port, 1 x COM, 1 x RJ45 LAN, 1 x PS/2 K/M, 4 x Serial port
|
|
|
|
BackToTop |
|
Industrial 5.25" / 3.5" Embedded Miniboard
|
|
|
|
LS-573
|
|
5.25"
Intel® Penryn platform with 6 x Intel® Giga LAN
|
|
|
|
Intel®
CoreTM 2 Duo processor with socket-P @ 667/800/1066
MHz FSB
Intel®
GM45 & ICH9M , DDR3 800/1066 MHz up to 4.0 GB
Onboard
VGA , HDTV
, 24-bit Dual Channel LVDS , Optional DVI
PCI
slot , Mini-PCI and PCI Express Mini card socket . 8-bit GPIO
Onboard
6 x Intel® Gigabit LAN , HD Audio , 6 x COM , USB 2.0
DC 9V ~ 24V full
range input or standard 20-pin ATX P/S
|
|
|
|
|
|
LS-572
|
|
Intel® Core™ 2
Quad with 2 x DVI or LVDS 5.25" SBC
|
|
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop , 800/1066/1333 MHz FSB Intel®
Q35 & ICH9DO , DDRII 667/800 MHz up to 4.0 GB
Onboard VGA , Dual
DVI or LVDS interface
1 x PCI slot & 1 x Mini-PCI socket
Onboard 2 x Intel® Gigabit LAN ,
HD Audio , LPT , SMBUS
1 x RS-232/422/485 & 5 x
RS232 , 8 x USB 2.0 , IrDA , GPIO
|
|
|
|
|
|
LS-571
|
|
Intel® Core™ 2
Duo 5.25" Motherboard
|
|
|
|
Intel® CoreTM 2 Duo
( Merom ) processor @ 800 MHz FSB
Intel® GME965
& ICH8M , DDRII 533 / 677
MHz up to 2.0 GB ,
Optional
onboard 1.0 GB DDRII SDRAM
Onboard VGA ,
TV-out , DVI , 18/24-bit Dual
Channel LVDS .
2 x Mini-PCI
and 1 x PCI slot onboard , Onboard 2 x Intel® Gigabit LAN
RS232/422/485 , HD Audio ,
SMBus , USB 2.0 ,
8-bit GPIO , LPT , FDD , IrDA ,
Compactflash socket
DC 12V input or standard 20-pin ATX power supply .
|
|
|
|
|
|
LS-570
|
|
Intel®
Core Duo / Core Solo Miniboard with 4 Gigabit Ethernet
|
|
|
|
5.25" Intel® CoreTM 2 Duo / CoreTM Duo solution Miniboard
Intel® CoreTM Duo / CoreTM Solo / Celeron M processor @ 533/667 MHz FSB
Intel® 945GME & ICH7M , 2 x 240-pin DDRII 533/677 MHz support up to 3.0 GB
Onboard VGA , LVDS , DVI
Onboard 4 x Intel Gigabit Ethernet controller
2 x SATA, 4 x COM, 6 x USB 2.0, LPT , GPIO ,
Onboard CompactFlash & Mini-PCI socket
Standard ATX power supply / Full range 8 ~ 24V DC input
|
|
|
|
|
|
LE-565
|
|
VIA
V4 Eden Fanless Miniboard with 4 Gigabit Ethernet
|
|
|
|
5.25" Embedded VIA Eden Miniboard
Embedded VIA V4 Eden 1GHz CPU
Onboard optional 256 MB DDR SDRAM & one184-pin DIMM support up to 1GB.
Onboard VGA with Max. 64MB system shard memory
Onboard 4 x Realtek RTL 8110S-32 Gigabit Ethernet controller
2 x SATA, 18-24-bit LVDS, 4 x COM, 4 x USB 2.0, LPT
Onboard CompactFlash & Mini-PCI socket, DC +12 input
|
|
|
|
|
|
|
|
Embedded Eden Platform w/ 4 LAN for Firewall Solution
|
|
|
|
5.25" EBX Embedded VIA Eden Miniboard
Embedded VIA Eden 533 MHz CPU / 133 MHz FSB
Onboard 128/256 MB PC133 SDRAM
Onboard CRT SVGA with Max. 8MB system shard memory
Onboard 2 LAN Solution with 4 x Realtek 8137C+ 10/100 Mbps
or 3 x Intel 82551QM 10/100 Mbps + 1 x Intel 82540EM 10/100/1000 Mbps
2 COM, 2 USB,1 Parallel Ports
Onboard CompactFlash Type-I/II Interfaces
|
|
|
|
|
|
Embedded Eden Platform for LVDS Pannel Solution
|
|
|
|
5.25" EBX Embedded VIA Eden Miniboard
Embedded VIA Eden 667/533 MHz CPU / 133 MHz FSB
Onboard 128/256 MB PC133 SDRAM
Onboard LVDS/TTL Flat Panel / CRT SVGA with 32 MB VRAM
Onboard Dual 10/100 Mbps LAN Interface
Onboard AC97 3D Audio, 4 COM, 4 USB, 2 Parallel Ports
Onboard PC/104-plus and CompactFlash Type-II Interfaces
|
|
|
|
|
|
Socket 370 Platform with PC/104-plus and 16-bit GPIO
|
|
|
|
5.25" EBX Socket 370 Tualatin Miniboard
Intel® Tualatin Pentium-III / Celeron, VIA C3 CPU @ 100/133 MHz FSB
Built-in LVDS/TTL TFT/DSTN LCD SVGA with 32 MB Video Memory
Optional AV / S-Video TV-out Interface
Onboard LAN, Audio Interface
Onboard 4 COM, 2 LPT, 2 USB and 16-bit GPIO Ports
Onboard PC/104, PC/104-plus and DiskOnChip Interfaces
|
|
|
|
|
|
5.25"
SBC with onboard Intel Celeron M 600 MHz CPU
|
|
|
|
5.25"
SBC with onboard Intel Celeron M 600 MHz CPU,
256 MB DDR SDRAM
Intel
852GM and ICH4 Chipset, Intel
GMCH integrated graphics controller VGA
Interface,
24-bit
dual channel LVDS support (optional)
Onboard
LAN, Audio Interface,1 x CompactFlash socket
Onboard
2 x COM, 6 X USB and 1
x 32-bit PCI slot
|
|
|
|
LE-374
|
|
3.5"
embedded board for Intel Atom solutions
|
|
|
|
Intel®
Atom N270 processor @ 533 MHz FSB
Intel®
945GSE & ICH7M chipset
DDR2 up
to 2.0 GB , DVI , LVDS and HDTV
Intel®
Giga LAN , SATA , USB2.0 , COM
Compactflash
and Mini-PCI socket , Audio
DC 9V ~
24V inputs
|
|
|
|
LS-373
|
|
3.5" Intel® Core 2
Duo (Penryn) based on GM45 chipset
|
|
|
|
Intel® CoreTM 2 Duo
processor with socket-P @ 667/800/1066 MHz FSB
Intel® GM45
& ICH9M , DDR3 800/1066 MHz up to 2.0 GB
Onboard VGA
, HDTV
, 24-bit Dual
Channel LVDS
Mini-PCI
and PCI Express Mini card socket . 8-bit GPIO
Onboard 2 x Intel® Gigabit LAN ,
HD Audio , SPDIF
RS232/422/485 , USB 2.0 , DC
12V input
|
|
|
|
|
|
LS-372
|
|
3.5" Intel® Core 2
Duo (Merom) @ 800 MHz FSB
|
|
|
|
Intel® CoreTM
2
Duo (Merom)
processor @ 800 MHz FSB
Intel® GME965 and
ICH8M chipset
DDRII
SO-DIMM up to 2.0 GB , Onboard VGA, TV-out / DVI
24-bit Dual
Channel LVDS , 1 x SATAII , 1 x
Mini-PCI socket
Onboard 1 x Intel Gigabit LAN ,
HD Audio ,SPDIF , RS232
USB 2.0 , 8-bit GPIO , CompactFlash socket ,
DC12V input
|
|
|
|
LS-371
|
|
3.5" Intel® Core 2
Duo / Core Duo / Core Solo Miniboard
|
|
|
|
Intel® CoreTM
2
Duo / CoreTM
Duo / CoreTM Solo processor , 533 / 667 MHz FSB
Intel® 945GME and
ICH7M chipset
DDRII
SO-DIMM up to 2.0 GB , Onboard VGA, DVI
18-bit Dual
Channel LVDS , 2 x SATA
1 x
Mini-PCI, Onboard 1 x Intel Gigabit LAN ,
5.1 channel Audio
RS232/422/485 , USB 2.0 , 8-bit GPIO ,
IrDA, CompactFlash socket
8 V ~ 24 V Full range DC input
|
|
|
|
|
|
LE-370CM6
|
|
3.5"
Fanless Embedded Celeron M 600MHz processor Miniboard
|
|
|
|
3.5" Fanless
Embedded Intel® ULV Celeron M Miniboard
Embedded Intel® ULV Celeron
M 600Mhz processor with 400MHz FSB
Intel® 852GM & ICH4
Chipset.DDR200/266 SDRAM up to 1GB
Onboard VGA,
24-bit Dual-channel LVDS Interface.
IDE1 support DOM with
+5V power supply.
Onboard 5-pin LCD
inverter connector and CompactFlash socket.
One Intel 10/100Mbps
LAN , 2 x USB , RS232 and IrDA ports
Mini-PCI and Audio
Interface.
|
|
|
|
LE-370
|
|
3.5"
Intel® Pentium M / Celeron M process Miniboard
|
|
|
3.5" Embedded
Intel Pentium M / Celeron M Miniboard
Intel® Pentium M /
Celeron M processor with 400/533MHz FSB
Intel® 852GME & ICH4
Chipset.DDR266/333 SDRAM up to 1GB
Onboard VGA,
24-bit dual channel LVDS Interface.
IDE1 support DOM with
+5V power supply.
Onboard 5-pin LCD
inverter connector and CompactFlash socket.
One Intel 10/100Mbps
LAN , 2 x USB , RS232 and IrDA ports
Mini-PCI and Audio
Interface.
|
|
|
|
LE-366
|
|
3.5"
Fanless Miniboard with AMD LX800 CPU
|
|
|
|
AMD Geode LX
800 process-based running at 500+ MHz
3.5"
Miniboard based on AMD LX800 , CS5536, DDR SO-DIMM up to 1.0 GB
18-bit
LVDS , AC97
Audio , Giga LAN , 4 x USB2.0 , 2
x COM
GPIO
, Mini-PCI socket,
CompactFlash socket , DC 12V input.
|
|
|
|
LE-365
|
|
3.5"
Fanless Miniboard with VIA Eden 1.0 GHz CPU
|
|
|
|
3.5"
Fanless Miniboard with VIA Eden CPU.
Embedded
VIA Eden 1.0G GHz CPU with 400 MHz FSB.
VIA CX700M
Chipset
200-pin
DDRII 400/533 SDRAM up to 1.0 GB
MPEG2
hardware accelerator integrated
Optional
18/24-bit
LVDS or DVI interface
2 x
Mini-PCI
and CompactFlash socket interface
Giga LAN ,
4 x USB 2.0 , 2 x COM . 2 x SATA Full
range 8 ~ 24V DC input
|
|
|
|
|
|
|
|
3.5" Fanless Miniboard with VIA Eden 800MHz CPU
|
|
|
|
3.5"
Fanless Miniboard with VIA Eden CPU.
Embedded
VIA 800MHz CPU with 133 MHz FSB.
VIA
CN400 &VT8237 Chipset
184-pin
DDR266/333/400 SDRAM up to 1GB
MPEGII/MPEG-4
hardware accelerator integrated
18/24-bit
LVDS interface
Mini-PCI
and CompactFlash socket interface
One
10/100Mbps LAN , 2 x USB 2.0 , 2 x COM
|
|
|
LE-363
|
|
3.5"
Fanless Low Power Miniboard with AMD GX533 Processor
|
|
|
|
3.5" Fanless
Miniboard with AMD GX533 processor. (1.1w )
Onboard optioal 128MB
DDR Memory and 1 x DDR SODIMM support up to 512MB.
Support 18/24-bit TTL/LVDS
interface . Dual 10/100Mbps LAN .
Mini-PCI & PCMCIA
slots interface .
CompactFlash Type-I
socket. IDE1 support 44-pin DiskOnModule
2 x RS232 , 2 x USB 1.1
, IrDA & 8-bit GPIO.
DC 12V Input.
|
|
|
|
|
|
Embedded VIA Eden 667 Platform
|
|
|
|
3.5" Embedded VIA Eden Miniboard
Embedded VIA Eden 667 MHz CPU
Low Profile 144-pin SO-DIMM Socket, onboard optional PC-133 128 MB SDRAM
Onboard Flat Panel / CRT SVGA /S-vedio TV-out interface
Onboard 10/100 Mbps LAN, USB 2.0 Interface
Onboard 3D Audio Interface
Onboard PC/104-plus and CompactFlash Interface
|
|
|
|
|
|
Embedded AMD GX1 with PC104 connector
|
|
|
|
3.5" Embedded AMD GXC1 Miniboard
Embedded Onboard AMD GX1 processor , AMD Geode CS5530 chipset.
1 x 144-pin SODIMM up to 256 MB, Geode GX1 Integrated 2D Technology
VGA Interface, 18-bit TTL TFT Flat Panel Support,
Onboard 10/100 Mbps LAN, USB 1.1 Interface
Onboard PC/104-plus and CompactFlash Interface
|
|
|
|
BackToTop |
Industrial Embedded Motherboard
|
| |
|
|
LV-682 |
AMD Mobile Turion
64 X2 Mini-ITX Motherboard |
|
|
Mini-ITX AMD Mobile Turion 64 X2
638-pin Processor
ATI RS690E &
SB600 Chipset
2 x 200-pin DDRII 533/667MHz
SO-DIMM support up
to 4.0 GB
ATI RADEON X-700 based 2D/3D graphics
engine
24-bit Dual channel LVDS ,
DVI connector , Audio
2 x SATA interface , 1 x
Mini-PCI
and 1 x PCI slot
Dual Giga LAN , 8 x USB 2.0 , 4
x COM ,
CompactFlash socket
|
| |
|
|
LV-67B |
Intel® Core™ 2
Duo Mini-ITX Motherboard |
|
|
Intel® CoreTM 2 Duo
processor with socket-P @ 667/800/1066 MHz FSB
Intel® GM45
& ICH9M , DDR3 800/1066 MHz up to 2.0 GB ,
Onboard VGA
, TV-out , 24-bit Dual
Channel LVDS .
PCI-Express
X16 , Mini-PCI
and PCI Express Mini card socket .
Onboard 2 x Intel® Gigabit LAN ,
7.1 channel HD Audio
RS232/422/485 , IEEE1394 ,
SPDIF , USB 2.0 ,
9V ~ 24V Full range DC input
or standard 20-pin ATX power supply . |
| |
|
|
LV-679
|
Intel® Core™ 2
Duo Mini-ITX Motherboard |
|
|
Intel® CoreTM 2 Duo
( Merom )processor @ 800 MHz FSB
Intel® GME965
& ICH8M , DDRII 533 / 677
MHz up to 3.0 GB ,
Onboard VGA
, 2 x DVI ,
TV-out , 24-bit Dual
Channel LVDS .
2 x Mini-PCI
and 1 x PCI slot onboard
Onboard 2 x Intel® Gigabit LAN ,
7.1 channel HD Audio
RS232/422/485 , IEEE1394 ,
SPDIF , USB 2.0 ,
8-bit GPIO , LPT , FDD , IrDA ,
Compactflash socket
9V ~ 24V Full range DC input
or standard 20-pin ATX power supply . |
|
|
|
|
LV-678
|
Intel® Core™ 2
Quad Mini-ITXexpress
Motherboard |
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop , 800/1066/1333 MHz FSB Intel®
Q35 & ICH9DO , DDRII up to 4.0 GB , Onboard VGA
1 x PCI-Express slot & 1 x
Mini-PCI socket
Onboard 2 x Intel® Gigabit LAN ,
HD Audio
RS-232/422/485 , 8 x USB 2.0 , IrDA , SPDIF , GPIO
|
|
|
|
|
LV-677
|
Intel® Core™Duo
/ Core™Solo Mini-ITXexpress
Motherboard |
|
|
Intel® CoreTM 2 Duo / CoreTM
Duo processor , 533 / 667 MHz FSB
Intel® 945GME
& ICH7M , DDRII 533 / 677
MHz up to 3.0 GB , Onboard VGA
18-bit Dual
Channel LVDS . 2 x Mini-PCI
and 1 x PCI-Express slot onboard
Onboard 1 x Intel® Gigabit LAN ,
5.1 channel Audio
RS232/422/485 , IEEE1394 ,
SPDIF , USB 2.0 ,
8-bit GPIO , LPT , FDD , IrDA
8 V ~ 21 V Full range DC input
or standard 24-pin ATX power supply . |
|
|
|
|
LV-676
|
Intel® Core 2 Duo
/ Pentium D Mini-ITX Motherboard |
|
|
Intel® CoreTM
2 Quad / CoreTM
2 Duo Desktop , 533/800/1066 MHz FSB Intel®
Q965 & ICH8DO , DDRII up to
3.0 GB , Onboard VGA ,
Optional LVDS or DVI interface
, 1 x Mini-PCI and 1 x PCI slot
Onboard 2 x Intel® Gigabit LAN ,
HD Audio
RS-232/422/485 , IEEE 1394 ,
USB 2.0 ,
IrDA , SPDIF , GPIO
|
|
|
|
|
LV-675
|
Intel® Pentium M /
Celeron M Mini-ITX Motherboard |
|
|
Intel® Pentium M / Celeron M ,
400/533 MHz FSB .
DDR333 up to 1 GB , Onboard VGA
Optional LVDS or DVI interface
S-video and Composite TV-out
connector ,
2 x Mini-PCI and 1 x PCI socket
Onboard 1 x Intel® Gigabit LAN ,
5.1 channel Audio
RS-232/422/485 , IEEE 1394 ,
USB 2.0 ,
| |
.jpg)
.jpg)
.jpg)
