CPU |
Onboard
VIA Eden 1.0 GHz processor |
|
Chipset
|
VIA
CN700 & VT8237R+ |
|
Memory |
1
x DDR up to
1.0 GB ( Optional 256 MB SDRAM onboard ) |
|
LAN Interface |
4
x Realtek RTL8110S-32
Gigabit Ethernet |
|
Solid
State Disk |
Dual
Channels support 4 ATAPI devices up to UDMA/133
|
|
SATA
Interface |
2
x Serial ATA interfaces with 150MB/s transfer rate
|
|
Extend
Interface |
1
x PCI slot & 1
x Min-PCI socket
|
|
External I/O
Port |
4
x RJ45 LAN
ports, 1 x DB15 VGA port, 2 x USB 2.0 ports, 1 x COM , DC input
connector
|
|
Power Requirement |
DC
12V input |
|
Board Dimension |
146mm x 203 mm (L x
W) |
|
Operation
Temp. |
0 ~
60ºC
(32 ~ 140ºF)
|
